13.7″ x 5.9″ x 3.9″ New Amada High Precision Forming Grinder Model Meister V3

Terms:  Check with Order

SKU: 36189 Categories: , ,

Description

13.7″ x 5.9″ x 3.9″ New Amada High Precision Forming Grinder Model Meister V3 Specifications:

Capacity
Table Working Surface (L x W) 17.7″ x 5.9″
Max. Longitudinal Travel 19.6″
Max. Cross Travel 7.8″
Spindle Center Height from Table 15.7″
Standard Chuck Size (L x W x H) 13.7″ x 5.9″ x 3.9″
Travel
Longitudinal feed
Max. no. of reciprocation 250 min-1*
Saddle
Rapid Cross Feed (jog) 0-1312 f/tmin, 1640 ft/min, 3280 ft/min
Handle Feed per Rev. 0.0004″, 0.004″, 0.04″, 0.15″
Handle Feed per Grad. 0.000004″, 0.00004″, 0.0004″, 0.0015″
Minimum Input Increment 0.000010″
Position Detection System Glass scale/0.05�m
Wheel Head
Rapid Wheel Head Feed (jog) 3.9″/min, 39″/min (2 steps)
Handle Feed per Rev. 0.0004″, 0.004″, 0.04″, 0.15″
Handle Feed per Grad. 0.000004″, 0.00004″, 0.0004″, 0.0015″
Minimum Input Increment 0.000010″
Position Detection System Linear scale 0.05 �m (OP)
Wheel Spindle
Wheel size (OD x Width x Bore) Ø8″ x 0.25″~1″ x Ø1.25″
Wheel Spindle Speed 500-5,000 RPM
Motor Requirement 3 HP – 2 P
NC Control Axis Simultaneously 2 axis
Floor Space (W x L x H) 74″ x 58″ x 74″
Machine Net Weight 4,840 lb



13.7″ x 5.9″ x 3.9″ New Amada High Precision Forming Grinder Model Meister V3 Features:

  • High-Speed Table Reciprication
    • AMADA Machinerys’ proprietary positioning scale and hydraulic servo system can achieve 250 min-1 high-speed reciprocation and significantly increase grinding efficiency.
  •  Optical Linear Scale for High Accuracy Positioning
    • The vertical axis is accurately positioned by fully closed feedback using a linear scale of 0.05 μm resolution (optional for MEISTER V3).
  • Full Cover Design Insusceptible to Thermal Displacement
    • The installed heat-insulating cover can cope with thermal symmetry structure and environmental change and assure workplace safety.
