Description
126 Ton New Marvel Spartan Ironworker MSIW126D Specifications:
| Punching |
|
| Punching Pressure |
126 Tons
|
| Punch Work Table |
Includes back gauge and adjustable stops.
|
| Adjustable See-Through Punch Stripper |
For fast and easy setup.
|
| Die Holder |
Adjustable in machined T-slots for quick punch and die alignment.
|
| Standard Tooling |
1-1/2″ in 1″ material
|
| CPD Series |
SP51P punch, SP80D die
|
| Large Tooling |
2″ in 3/4″
|
| Optional Oversize Tooling |
4-5/16″ in 5/16″ material
|
| Throat Depth |
14” (D); 24” (DX)
|
| Stroke Length |
3-1/8”
|
| Cycles Per Minute in 3/4″ |
25
|
| Punching Station Work Height |
43-3/4”
|
| Flat Bar Shearing |
|
| Flat Bar Shear Capacity |
14” in 1”
|
| Maximum Width x Thickness |
24” x 9/16”
|
| Lower Blade |
Four usable edges.
|
| Support Table |
Includes guides for accurate positioning and indicator lines at 30 and 45 Degrees left and right.
|
| Adjustable Hold-Down |
Holds work piece securely in position when shearing.
|
| Upper Shear Blade |
Provides for minimum distortion. Two usable edges.
|
| Blade Length |
24″
|
| Angle Flange Trim |
5″ in 5/8″
|
| Flat Bar Shear Work Height |
37″
|
| Angle Shearing |
|
| Max. Capacity – 90 Degrees |
6″ x 6″ x 5/8″
|
| Max. Capacity – 45 Degrees |
3″ x 3″ x 3/8″
|
| Shear Blades |
Four usable edges.
|
| Angle Shear Work Height |
48″
|
| Bar Shearing |
|
| Round Bar Max. Capacity |
2″
|
| Square Bar Max. Capacity |
2″ x 2″
|
| Six Cavity Round Bar Shear Size |
3/4″, 1-1/2″, 2″
|
| Six Cavity Square Bar Shear Size |
1-1/4″ to 2″
|
| Channel Shear Max. |
7″
|
| I-Beam Shear Max. |
7″
|
| Bar Shear Work Height |
48″
|
| Notching |
|
| Rectangular Notcher |
2-3/8″ x 4″ x 1/2″
|
| Gauge Table with Stops |
For precise positioning
|
| Notcher Work Height |
37″
|
126 Ton New Marvel Spartan Ironworker MSIW126D Standard Work Stations:
- Punching Station
- Punch Die Holder
- Punch Table
- Bar Shearing Station
- Angle Shear
- Flat Bar Shear
- Notching Station
126 Ton New Marvel Spartan Ironworker MSIW126D Optional Accessories:
| MSIW126PA18191 | V-Notcher | $5,380.00 |
| MSIW126PA18198 | Bending Single V | $4,670.00 |
| MSIW126JA01368 | Bending Multi V | $6,080.00 |
| MSIW60PA18160 | Electric Back Gauge 6 ft. (in place of standard 3 ft.) | $2,610.00 |
| MSIW126/340308 | Flat Bar Shear Hydraulic Hold-Down (special order) | QUOTE |
| MSIW126PA18207 | Channel Web Die Holders | $3,340.00 |
| MSIW126JA18505 | Oversize Punching Kit | $3,500.00 |
| MSIWIWA/CS126D23A | 3″ Channel Shear | $5,690.00 |
| MSIW126JA21983 | 4″ Channel Shear | $5,690.00 |
| MSIWA/CS126D45A | 5″ Channel Shear | $5,690.00 |
| MSIW126JA2184 | 6″ Channel Shear | $5,690.00 |
| MSIW126EK21625 | Voltage Conversion Kit (460 volts) | $1,550.00 |
