16″ x 32″ New SG Supertec Surface Grinder Model SG1632

Heavy Duty Meehanite Castings to Maximize Accuracy

Price On Request
F.O.B. Factory
Terms:  Check with Order





SKU: 4250 Category:

Description

16″ x 32″ New SG Supertec Surface Grinder series of precision surface grinders incorporates the latest in machine tool design, combining state of the art electronic with heavy duty reinforced Meehanite castings to maximize machine accuracy and repeatability.

16″ x 32″ New SG Supertec Surface Grinder Model SG1632 Specifications:

Max. Cross x Longitudinal Travels 18″ x 35″
Spindle Center Height from Table 23.6″
Grinding Surface Table 16″ x 32″
Hydraulic Motor 2 HP
Wheel Dimension 14″ x 1.5″ x 5″
Max. Ht from Table Top to Bottom of Standard Wheel 16.6″
Spindle Motor 7.5 HP
Spindle Speed 50/60 Hz 1800 RPM
Net Weight 6160 Lbs



16″ x 32″ New SG Supertec Surface Grinder Model SG1632 Features:

  •  Double “V” ways on Longitudinal & Cross Axes
  •  3 Axes Automatic
  •  Auto Downfeed
  • Auto Lube System
  •  Spindle Run-Out 0.0001″ TIR



Equipped with:

  • Grinding Wheel w/Flange 14″ x 1.5″ x 5″
  • Balance Arbor
  • Table Mounted Diamond Dresser
  • Tool Box w/Tools & Leveling Screws
  • Electromagnetic Chuck
  • Chuck Control w/ Variable Holding Power
  • Coolant System w/ Paper Filter
  • Splash Guard
