Description
16″ x 71″ New Clausing Horizontal Mill Model 5HM Specifications:
| Table | |
| Table area | 15.7″ x 70.8″ |
| Total load capacity | 2,200 lbs |
| No. of T-slots | 4 |
| Distance between T-slots | 3.14″ |
| T-slot size | 0.708″ |
| Spindle center to table (horizontal) | 3.5″ – 22″ |
| Travels | |
| X automatic travel longitude | 49.2″ |
| X axis rapid travel rate | 78.7 ipm |
| X axis feed rate | 0.62 – 47.2 ipm |
| Y automatic travel cross | 19.7″ |
| Y axis rapid travel rate | 78.7 ipm |
| Y axis feed rate | 0.62 – 47.2 ipm |
| Z automatic travel up/down | 18.5″ |
| Z axis rapid travel rate | 27.5 ipm |
| Z axis feed rate | 0.3 – 17.7 ipm |
| Spindle (Horizontal) | |
| Spindle taper | NT#50 |
| Milling arbor | 1″ |
| Number spindle speeds | 8 |
| Spindle speed range | 95 – 1200 rpm |
| Spindle motor HP | 7.5 |
| Servo Motors | |
| Longitudinal | 2 Hp |
| Cross feed | 2 Hp |
| Vertical | 2 Hp |
| Cooling | |
| Cooling pump | 1/8 Hp |
| Lube | |
| Lube pump | 4W |
| Weight | |
| Net weight | 6,600 lbs |
| Shipping weight | 7,310 lbs |
| Dimensions | |
| Machine dimensions (L x W x H) | 118.1″ x 99.8″ x 75.6″ |
| Floor space required | 167.3″ x 99.8″ |
16″ x 71″ New Clausing Horizontal Mill Model 5HM Standard Equipment:
- 7.5 Hp main spindle motor
- Variable feed speed for 3 axis
- Auto central lubricating system
- High quality meehanite casting for superior rigidity and wear resistance
- All gears and shafts are hardened and ground
- Large 15.7” x 70.8” (400 x 1800mm) table with 4 T-slots
- Extra large dovetail and dovetail slide ways for greater accuracy
- All slide ways and table are hardened and ground
- Turcite “B” on X/Y/Z axis ways
- Automatic coolant system and coolant pump
- Tool box and service tools
16″ x 71″ New Clausing Horizontal Mill Model 5HM Optional Accessories:
| Factory order only | |
| 5HM01 CE Electrics w/Spindle Brake and Table Guard Electronic Filter | $14,755.00 |
| 5HM50 X / Y / Z Ball Screws | $6,625.00 |
| 5HM60 Spindle Auto Braking System Only | $3,100.00 |
| 5HM80A Table Guard for Table | $2,715.00 |
| 5HM90 Lower Pendant Arm for Controls | $2,100.00 |
| 4HM100A Motor Upgrade 15 Hp in Lieu of 7.5 Hp | $2,100.00 |
| 5HM310 X-Axis Telescopic Cover | $1,510.00 |
| Non-factory order | |
| 5HM30 6” Rotary Vise | $2,395.00 |
| 5HM40 15.7” x 31.4” Magnetic Chuck | $9,975.00 |
