Description
17″ x 27″ New Clausing Horizontal Miter Bandsaw Model MS1727NC Specifications:
| Motor | 7.5 Hp, 230v 3 Ph |
| Hydraulic pump motor | 2 Hp |
| Hydraulic oil capacity | 19.2 gallons |
| Blade speeds (variable speed) | 66-330 fpm |
| Blade size (W x T x L) | 1.5″ x 0.050″ x 228″ |
| Blade tension | Hydraulic |
| Coolant | Recirculating |
| Coolant capacity | 31.2 gallons |
| 90º cutting capacity | Round 17.7″ Rectangular 17.7″ x 27.5″ |
| 45º cutting capacity | Round 17.7″ Rectangular 17.7″ x 20.5″ |
| 60º cutting capacity | Round 11.8″ Rectangular 17.7″ x 11.8″ |
| Length | 166.5″ |
| Width | 130″ |
| Height | 107″ |
| Bed height | 29.5″ |
| Net weight | 5,500 lbs. |
| Shipping weight | 6,160 lbs. |
17″ x 27″ New Clausing Horizontal Miter Bandsaw Model MS1727NC Features:
- Swivel sawhead mitering from 90° to 60° left to 45° right
- Rigid and heavy-duty pivot and trunion
- Sturdy cast work table
- 24.4” solid discharge table with coolant return
- Variable speeds from 66 thru 330 fpm
- Carbide blade guides with roller bearings
- Two additional bearings to support the blade from the top
- Cast iron guide arm supported by heavy-duty cast iron dovetail
- Automatic hydraulic blade tensioning
- Integral coolant system
- Synchronized blade brush
- Precision feed pressure & feed rate dual valve system
- Conveniently designed control station
- Electrical components located inside the control box with main lockout disconnect
- Work height selector
- Industrial rated hydraulic components
- Full stroke machine vises
- Breakage detector
- Built-in adjustable material stop
- Adjustable work light
- Additional flushing hose
- Bi-metal saw blade
- Tool box, leveling pads and an additional wire brush
- Operation and parts manual
- Two (2) year limited warranty
17″ x 27″ New Clausing Horizontal Miter Bandsaw Model MS1727NC Optional Accessories:
| P10 Stock Stand Assembly 21”-30” Height | $345.00 |
| VP17NC Vise Press Regulator (factory installed) | $1,875.00 |
| CLAUS2-A12K Transformer (208 volt to 230 volt) | $1,020.00 |
| CLAUS1-A12K Transformer (460 volt to 230 volt) | $1,440.00 |
| CM1701MC Chip Conveyor | $2,210.00 |
| CM1702MC Hydraulic Bundle Clamps | $3,395.00 |
| MS17-AMP Motor Load Meter factory installed | $1,440.00 |
| MS17-SHD Stock Height Detector factory installed | $560.00 |
| MS17-BDD Blade Deviation Detector factory installed | $2,335.00 |
| MS17-AWR Automatic Wedging Resistance | $1,440.00 |
| SA26 H.D. Roll Table 25” x 10’ x (24”-32”) 3” Ctr. (10K cap) | $3,240.00 |
| SA27 H.D. Roll Table 25” x 5’ x (24”-32”) 3” Ctr. (10K cap) | $1,890.00 |
| CSR1 SAWZIT 1 Gallon Coolant | $40.00 |
| CSR5 SAWZIT 5 Gallon Coolant | $145.00 |
