Description
20″ x 29.5″ New Clausing Horizontal Bandsaw Model H2030SA Specifications:
| Motor | 7.5 Hp, 230v 3 Ph |
| Hydraulic pump motor | 2 Hp |
| Hydraulic oil capacity | 10 gallons |
| Blade speeds (variable speed) | 66-328 fpm |
| Blade size (W x T x L) | 2″ x 0.063″ x 238″ |
| Blade tension | Hydraulic |
| Coolant | Recirculating |
| Coolant capacity | 21.5 gallons |
| 90º cutting capacity | Round 20″ Square 20″ Rectangular 20″ x 29.5″ |
| Length | 122.9″ |
| Width | 42.2″ |
| Height | 82.1″ |
| Bed height | 27.5″ |
| Net weight | 5,016 lbs. |
| Shipping weight | 5,720 lbs. |
20″ x 29.5″ New Clausing Horizontal Bandsaw Model H2030SA Features:
- Twin column design ensures rigid support during cutting cycle by keeping the blade parallel and square to the work piece
- Infinitely variable speed
- Digital blade speed indicator
- Carbide blade guides with roller bearings
- Two additional guides to support the blade from the top
- Automatic hydraulic blade tensioning
- Power driven blade brushes
- Integral coolant system
- Last cut selector switch
- LCD digital blade speed monitor
- Precision feed pressure & feed rate
- Cast iron vises with replaceable hardened wear plates
- Discharge table with built-in coolant return
- Blade slippage or breakage detection
- Additional flushing hose
- Bi-metal saw blade
- Built in work light
- Tool box, leveling pads and an additional wire brush
- Operation and parts manual
- Two (2) year limited warranty
20″ x 29.5″ New Clausing Horizontal Bandsaw Model H2030SA Optional Accessories:
| VP20SA Vise Pressure Regulator Single Vise | $1,330.00 |
| CLAUS2-A12K Transformer (208 volt to 230 volt) | $1,020.00 |
| CLAUS1-A12K Transformer (460 volt to 230 volt) | $1,440.00 |
| CM2001H Chip Conveyor | $2,305.00 |
| CM2002H Hydraulic Bundle Clamp | $1,700.00 |
| SA26 H.D. Roll Table 25” x 10’ x (24”-32”) 3” Ctr. (10K cap) | $3,240.00 |
| SA27 H.D. Roll Table 25” x 5’ x (24”-32”) 3” Ctr. (10K cap) | $1,890.00 |
| CSR1 SAWZIT 1 Gallon Coolant | $40.00 |
| CSR5 SAWZIT 5 Gallon Coolant | $145.00 |
