Description
51″ x 67″ New Clausing Horizontal Bandsaw Model H5167SA Specifications:
| Motor | 20 Hp, 230v 3 Ph |
| Hydraulic pump motor | 3 Hp |
| Hydraulic oil capacity | 35 gallons |
| Blade speeds (variable speed) | 49-264 fpm |
| Blade size (W x T x L) | 3″ x 0.063″ x 512″ |
| Blade tension | Hydraulic |
| Coolant | Recirculating |
| Coolant capacity | 44 gallons |
| 90º cutting capacity | Round 51″ Square 51″ Rectangular 51″ x 67″ |
| Length | 118″ |
| Width | 232″ |
| Height | 166.5″ |
| Bed height | 24.4″ |
| Net weight | 48,500 lbs. |
| Shipping weight | 51,410 lbs. |
51″ x 67″ New Clausing Horizontal Bandsaw Model H5167SA Features:
- The extra heavy-duty saw frame is supported by two large bore hydraulic cylinders, providing unsurpassed rigidity and the smoothest cutting possible
- Dual column design with precision ground columns ensures smooth saw frame movement and consistent cutting force throughout the cutting cycle
- Specially designed planetary gear reducer for optimum mechanical efficiency
- Inverter controlled infinitely variable blade speed with blade speed indicator
- Hydraulically powered guide arm is position from the control panel
- Hydraulic Blade Tension System with easy to read pressure gauge
- Carbide blade guides are activated hydraulically
- Additional blade guiding bearings for extra support
- Heavy cast iron moveable guide arm is hydraulically powered from the control panel
- Auto shut off function
- User-friendly control panel
- Precision feed pressure control valve with micro-precision adjustment
- Saw blade height selector
- Hydraulic driven work bed with rollers for moving large material safely
- Three sets of vises designs. The front and middle vises hold the stock during cutting while the guide vise can be separately controlled to guide the material during feeding cycle
- Stock position cylinder pushes stock away from fixed vise for easy material handling
- Shadow light for material measurement
- Blade breakage and/or slippage detector
- Bi-metal saw blade
- Tool box, leveling pads and an additional wire brush
- Operation and parts manual
- Two (2) year limited warranty
51″ x 67″ New Clausing Horizontal Bandsaw Model H5167SA Optional Accessories:
| VP51SA Vise Pressure Regulator Single Vise | $2,445.00 |
| CM5101H Chip Conveyor | $2,565.00 |
| CM5102H Hydraulic Bundle Clamp | $5,235.00 |
| CLAUS2-A30K Transformer (208 volt to 230 volt) | $1,520.00 |
| CLAUS1-A30K Transformer (460 volt to 230 volt) | $1,910.00 |
| CSR1 SAWZIT 1 Gallon Coolant | $40.00 |
| CSR5 SAWZIT 5 Gallon Coolant | $145.00 |
