8' x 14ga New Kodiak Electrical Mechanical Shear

6′ x 10ga New Kodiak Mechanical Shear Model KPS-610M

Price On Request
F.O.B. Factory
Terms: Check with Order

Voltage *

Required: Enter your voltage requirements.

SKU: 39490 Categories: ,

Description

6′ x 10ga New Kodiak Mechanical Shear Model KPS-610M Specifications.

Mild Steel – HRS (tensile 60,000 PSI)
Stainless Steel (tensile 85,000 PSI)
Soft Aluminum (tensile 28,000 PSI)
min. thickness

6′ x 10Ga.
6′ x 14Ga.
6′ x 1/4″
22Ga

Blade Length 80″
Strokes per Minute 28
Worktable Height 32″
Front Support Arm 36″
Back Gauge 26″ Manual Back Gauge
Blade Rake Angle 2.5 Degrees
Main Motor 7.5 HP, 220V , 3 Phase
Machine Dimensions 100″ x 43″ x 68″
Weight 5,550 Lbs. – 5,650 lbs shipped

Features:

  • ISO 9001 certified
  • American design and Taiwan quality machine
  • HD all steel construction for maximum rigidity
  • Precision driven gearbox
  • Full length 30 strokes per minute
  • 60” long squaring arm with inch / mm scale
  • spring hold-downs
  • high grade carbon/chrome alloy steel blades and hardened to 62 hrc,
  • 2-edge indexable upper blade and 4-edge indexable bottom blade
  • Full length with full view finger guard
  • Front supports and (2) side gauges
  • Safety type foot pedal control
  • Jog, single continuous auto operation modes
  • One year warranty for parts



Standard Accessories:

  • 26” manual back gauge with one side handwheel
  • 60” long squaring arm with inch / mm scale, mounted on right side of the table
  • 2 each 24” front support arms
  • Full length finger guard
  • Removable safety foot pedal control
  • One set of upper & lower blades

Optional Accessories:

  • Safety fence for enclosure of the back side of the machines … $1,250.00
