Description
The most popular and most trusted name in roll bending brings you the CP60H Universal Bending Machine with Hydraulic Bending Roll, DP7 400 Position Touch Screen Programmable Auto-Repeat Control with direct radius input capability. This versatile unit can roll standard & special sections as well as tube & pipe.
Our Efficient CP60-H Pyramid Design has 30% Higher Weight, 30% Higher Horsepower, 100% more reliable frame, 100% Superior Warranty than any ‘Look Alike’ brands. Our Limited Lifetime Warranty on the mainframe is offered since we do not use frame castings, as do most other brands. Cast frames crack but Our Alloy Steel Frames Last a Lifetime.
New Eagle Bending Universal Roll Bender Model CP60-H Specifications:
| Shaft diameters | 2-3/8″ |
| Roll diameters | 8-7/8″ nominal 225mm |
| Drive motor | 3.5HP at 220V/3/60Hz |
| Pump motor | 2.5HP at 220V/3/60Hz |
| Floor area | 37″ x 51″ |
| Voltage | 220V or 440V-3Phase |
| Speed-CP60H REV | 0-28 fpm variable |
| Working height | 35″ |
| Drive rolls | 2 |
| Forming roll adjust | Hydraulic |
| Weight (machine) | 2,425 lbs |
| Crate dimensions | 42″ x 57″ x 72″ |
| Speed CP60H | 7.0 rpm (13 fpm) |
New Eagle Bending Universal Roll Bender Model CP60-H Bending Capacities:
| Flat bar on edge | 3-1/2″ x 5/8″ |
| Solid round bar | 2″ |
| Flat bar on flat | 5″ x 1″ |
| Schedule 40 pipe | 2-1/2″ |
| Square bar | 2″ |
| Round tube | 3-1/2″ |
| Rectangular tube HW | 3″ x 1-1/2″ x 1/8″ |
| Channel sections | 5″ x 2″ |
| Rectangular tube EZ | 1-1/2″ x 4-3/4″ x 1/8″ |
| Tee sections | 3″ x 5/16″ |
| Square tube | 2-3/4″ x 2-3/4″ x 11 Ga |
| Junior beams EZ | 4″ x 2″ |
| Angle iron | 2-1/2″ x 5/16″ L-In; 3″ x 1/4″ L-Out |
| Junior beams HW | 3″ x 1-3/4″ |
New Eagle Bending Universal Roll Bender Model CP60-H Features:
- Rugged steel frame, normalized, produce on CNC machining centers. New base frame have a wider base and a lower center of gravity for lower working height
- We use NO CASTINGS in our machine frames, ALL SOLID ALLOY STEEL
- High Strength Steel Shafts, heat-treated and ground, drive components and shafts all journaled in dual spherical self-aligning roller bearings
- Oil Bath Speed Reducer and high efficiency spur gear final drive with bi-directional TEFC-IEC rated electric drive motor
- Hydraulic Powered Forming Roll moves on hardened guides & ways with protective covers and adjustable Gibbs, lesser quality machines do not compare
- Hydraulic Power Unit incorporates overload relief & P.O. non-return valves, Our Hydraulic cylinders have NO EXTERNAL EXPOSED OIL LINES
- Dual Lateral Material Guides, heavily dimensioned, 4 ways adjustable. Large steel adjusting rods use recessed hex for ratchet type adjustment, far superior to any others
- Universal rolls with 18 components and calibrating spacers, hardened and wear resistant. Lower shafts driven, lower rolls knurled, top shaft idle smooth roll set
- Operates in both Vertical & Horizontal Positions and rests on isolating pads
- Low voltage controls on remote pulpit with push buttons, heavy-duty foot pedals and emergency stop. High quality ‘Siemens’ brand motor controls throughout. Flush mount NEMA type electrical cabinet with running light, emergency condition lamp and motor overload reset indicators
- Linear transducer, Digital Readout & Pre-Set System for precise automatic repeat
- Programmable bending roll positioning using 400 position MPR-40!!
- Coiling, pipe bending, leg-in angle, wide flat bending and other special tooling available
- Illustrated Instruction Manual, English (Spanish on request) & Service Tool Kit
New Eagle Bending Universal Roll Bender Model CP60-H Optional Accessories:
| Tube Rolls 1/8″ | $1,350 |
| Tube Rolls 1/4″ | $1,350 |
| Tube Rolls 3/8″ | $1,350 |
| Tube Rolls 1/2″ | $1,350 |
| Tube Rolls 5/8″ | $1,350 |
| Tube Rolls 3/4″ | $1,450 |
| Tube Rolls 1″ | $1,450 |
| Tube Rolls 1-1/4″ | $1,450 |
| Tube Rolls 1-1/2″ | $1,450 |
| Tube Rolls 1-5/8″ | $1,550 |
| Tube Rolls 1-3/4″ | $1,550 |
| Tube Rolls 1-7/8″ | $1,550 |
| Tube Rolls 2″ | $1,550 |
| Tube Rolls 2-1/4″ | $1,640 |
| Tube Rolls 2-1/2″ | $1,850 |
| Tube Rolls 2-3/4″ | $1,850 |
| Tube Rolls 3″ | $2,050 |
| Pipe Rolls 1/4″ | $1,350 |
| Pipe Rolls 3/8″ | $1,350 |
| Pipe Rolls 1/2″ | $1,350 |
| Pipe Rolls 3/4″ | $1,450 |
| Pipe Rolls 1″ | $1,450 |
| Pipe Rolls 1-1/4″ | $1,550 |
| Pipe Rolls 1-1/2″ | $1,650 |
| Pipe Rolls 2″ | $1,650 |
| Pipe Rolls 2-1/2″ | $2,050 |
| Set of rolls for angle iron let-out & leg-in w/ quick gap adjustment | $1,200 |
| Special Lateral Guides for Leg-in angle rolling with adjustable cam rollers | $2,675 |
| Special rolls for tight diameters, knurled (for solid square, round & flat bar stock only) | $1,750 |
| Special rolls for wide flats, lower rolls knurled, top roll smooth | $2,860 |
