Description
New Ercolina Rotary Draw Super Bender Machine Model SB48 Series Specifications:
Ercolina SB48 Super Bender is ideal for producing consistent quality bends in large diameter pipe, tubes, squares, rectangular, solids and other profiles.
Ercolina’s affordable tube benders and fabricating machines are designed to reliably and accurately produce your bending applications. As a result, our machines will increase profit, as well as improve product quality and finish.
| Mild steel tube Capacity | min- 1/4″ / max- 2″ |
| Pipe Capacity | 1-1/2″ Sch. 40 |
| Centerline Radius | min- 2 x Ø / max- 8⅞″ |
| Degree of Bend | 0-210° |
| Bending Speed | Fixed Speed |
| Programming |
Touch screen, Program storage, Multiple bends per program |
| Voltage |
110V Single Phase |
| Length, Width, Height |
22½″ x 16¼″ x 39½″ |
| Square tube capacity | 1-1/2″ .083 wall |
| Maximum CLR | 8-7/8″ |
| Drive Diameter | 40mm/50mm |
| Weight | 300lbs |
New Ercolina Rotary Draw Super Bender Machine Model SB48 Series Features:
- 120V 1ph
- Touch screen programming of bend angle with system diagnostics in multiple language capability
- Quick-change tooling system with multiple radii available
- Digital display of bend angle
- Foot pedal control for hands-free operation
- Counterbending die positioning monitored electronically for accuracy and repeatability
- Accepts Ercolina’s A40-P two axis positioning table for multiple and sequential bends
- Portable with base wheels and lift handle
- No hydraulic components
- All capacities based on A53 grade A 48,000 psi tensile materials; heavy wall and high tensile materials reduce machine capacity. Consult supplier for material specifications.
- Bend to CLR as small as 2D
- Bend any angle to 180° with independent material springback compensation for each bend
New Ercolina Rotary Draw Super Bender Machine Model SB48 Series Optional Accessories and Kits:
|
SB48-P: machine with PIPEKIT2 (5) pc tooling set |
$18,500.00 |
|
SB48-TSR: machine with Small Radius TUBEKIT2SR (5) pc tooling set |
$18,500.00 |
|
SB48-T: machine with Large Radius TUBEKIT2 (6) pc tooling set |
$20,900.00 |
- Spray Bending Lubricant
- Cap Rail Tooling
- Center Former Reinforcement Kit
- Counter bending Die Support
- Roller Counter bending Dies
- Rotary Draw Tie Bar Accessory
- Material Extraction Device For Square Tube
- A40/P TWO AXIS POSITIONER
- Counter bending Die Adaptor Plate
- Super Bend-Tech SE
